4-post heavy-duty vehicle lift – 22 tonnes
Mobile lorry lift: 22 t, available in a 6-wheel version. Ideal for confined spaces, as easy to move as a forklift and suitable for use on any type of firm, level ground. This lorry lift features highly robust technology.
Product overview
Features
- 1A Quality built with CE certificate
- Manufactured according to ISO 9001
- Qualité supérieure et construction massive
- Checking each column
- The control system can switch from a single lift to a shared lift.
- Lifting jacks are easy to move.
- 4 powerful electric motors for lifting
- An adapter for the conveyor is available as an optional extra
Technical data
Lifting capacity
22000 kg
By column
5500 kg
Max. lift height
1600 mm.
Lifting/lowering time
10 mm/s
Power supply
4x 3,0 kW
Engine power
400 V / 3 phases
Fuse protection
32 A
Weight
2400 kg
Colour
RAL 5015 (Blue), RAL 7000 (Grey)
TW550-4 - Overview
Contents of the delivery
- Complete lorry lift
- Instructions for use and care
- Examination book, 1A Quality built with CE certificate
- Oil is not included – it can be ordered as an optional extra
- Car not included
